Overview
55-SERIES
A 21st century reinvention of McConnel’s iconic PA93, the 55-series offers a winning combination of power, performance and value for money.
Three models of the 55 Series are available; the PA5155 with 5.1m reach, 55hp hydraulics, the PA5455 with 5.4m reach, 55hp hydraulics and the range topping PA5555-60 with 5.5m reach and 60hp hydraulic system. The later of the models comes fitted with an integrated oil cooler as standard to ensure longevity with the step up in horsepower.
All models are offered with a wide range of attachments and customisation options – increasing versatility and enabling customers to create a machine to match their precise personal requirements.
OVERVIEW
Designed for farmers, contractors and local government green maintenance teams, 55-series machines are robust and reliable with cast-iron pumps and gearboxes and high-capacity oil filters as standard.
Available with a VFR, hy-reach and parallel arm geometry, hydraulic safety breakaway, Power Slew, and a wide range of attachments, the 55-series offers enhancements that are the envy of other mainstream mid-range Power Arms.
55-SERIES POWER ARM IN ACTION
See the 55-series hedge cutting:
FEATURES
Versatility
With a wide choice of work attachments including cutterbars, rotary heads, Multisaws and a ditch and grip cleaner, 55-series machines can tackle far more than just hedge-cutting and verge-mowing – enabling contractors to expand the services they can offer their customers.
Tackle tough tasks
55-series machines can be specced with McConnel’s heavy-duty Omega rotor and flails, or a 1.5m Multicut flailhead with heavy duty F14 flails– McConnel’s most powerful cutting tool. Either combination will make light work of the toughest clearance jobs, including hedges with three years growth.
Benefits
- Extremely versatile work platform
- Solid feature set
- Highly customisable
- Capable of tackling some of the most challenging green maintenance tasks
- Improved comfort, visibility and safety delivered by the optional Variable Forward Reach armse
- Precise proportional controls
- Robust build quality
- Smooth arm movements
- Popular and proven around the world
- Modest power requirement
Key Features
5.1m and 5.4m reach
Choice of three advanced control systems
Choice of electric and rotor controls
55hp and 60hp hydraulics
Three-point linkage
Variable Forward Reach available (PA5155 only)
Lift and float angle kits
Hydraulic safety breakaway
Hydraulic roller option
Power Slew
Choice of eight different flailheads
Choice of 13 working attachments
Technical Specifications
Model | PA5155 | PA5455 | PA5555-60 |
---|---|---|---|
Reach | 5.1m | 5.4m | 5.5m |
Machine weight* | 881kg | 895kg | TBC |
Tractor hp requirement | 70hp | 70hp | 70hp |
Tractor weight requirement | 3000kg | 3500kg | 3500kg |
Brochure
Find out more about this product by downloading our brochure
Specifications
Evolution Control
OVERVIEW
Created for customers who demand outstanding precision and functionality, EVOLUTION offers eight-function controls; joystick technology pioneered by McConnel’s acclaimed REVOLUTION system; and a robust design capable of withstanding the demands of busy professional contractors.
Five proportional functions* are available for precise fingertip control, while the joystick enables operators to customise the controls to suit their personal preferences or the job at hand.
A new software package developed exclusively for McConnel by industry specialists offers simple yet sophisticated functionality, while the rugged new control pod has an ergonomic key layout which enables fast and intuitive one-handed control.
FEATURES
Proven joystick technology
EVOLUTION features the same proven joystick built into McConnel’s flagship controller REVOLUTION, enabling light and precise fingertip control of complex manoeuvres as well as easy key mapping and bullet-proof build quality.
Advanced Float cruise control
Created as a value-for-money cruise control system, Advanced Float automatically adjusts the height of the flailhead to suit the contours of the ground when used in conjunction with an angle float kit, leaving the operator to regulate only the reach. More effective and flexible than a standard lift float kit, the system thrives on embankments and verges and enhances working speeds, comfort and visibility without the need for resetting.
Benefits
- Advanced new eight-function controller
- Five proportional functions
- Uses acclaimed REVOLUTION joystick technology
- Ergonomic key layout
- Cruise control
- Advanced control-mapping options
- Light intuitive control
- Smooth learning curve
- Complex functionality
- State-of-the-art software package
- Comfortable arm rest available
- Rugged build quality
SUITABILITY | |||||
---|---|---|---|---|---|
Cable | MOTION Mini | MOTION | EVOLUTION | REVOLUTION | |
Swingtrim | X | X | |||
30-Series | X | X | |||
45-Series | X | X | |||
55 Eco-Series | X | X | |||
55-Series | X | X | X | ||
60-Series | X | X | X | X | |
65-Series | X | X* | X | ||
70-Series | X | X | X | ||
85-Series | X | X | X | ||
VERSI-Series | X | X | X |
* Please note – Only three proportional functions are available on 65-series Power Arms.
Downloads
Motion Control
OVERVIEW
McConnel’s MOTION control system is an easy-to-master seven-function (six proportional) controller which offers light and precise fingertip control of complex manoeuvres and operations.
Featuring an ergonomic control pod, sophisticated software and a precise ‘short-stick’, the system has been created to be rugged, responsive and reliable.
FEATURES
Purpose-built software
McConnel has teamed up with a leading industry specialist to ensure the best in functionality and performance, creating a new software system that is simple to master yet extremely sophisticated. The system was built exclusively for MOTION and has been designed to deliver intuitive control and a consistent, reliable performance.
Enhanced comfort
MOTION is available with a reinforced polyurethane foam armrest which is not only hard-wearing and durable, but also offers greater comfort.
Benefits
- Up to six proportional functions
- Light, intuitive control,
- Ergonomic short stick for precise fingertip control
- Easy to master
- Complex functionality
- Revamped software
- Comfortable
- Rugged build quality
SUITABILITY | |||||
---|---|---|---|---|---|
Cable | MOTION Mini | MOTION | EVOLUTION | REVOLUTION | |
Swingtrim | X | X | |||
30-Series | X | X | |||
45-Series | X | X | |||
55 Eco-Series | X | X | |||
55-Series | X | X | X | ||
60-Series | X | X | X | X | |
65-Series | X | X | X | ||
70-Series | X | X | X | ||
85-Series | X | X | X | ||
VERSI-Series | X | X | X |
Downloads
Cable Controls
OVERVIEW
Simple, no-frills, three axis progressive controller that’s easy-to-learn.
Operates Power Arm lift, reach and flailhead angling functions, while additional levers control the Power Slew, breakaway reset, and the start, stop and reverse functions of the rotor.
Ideal for those looking for a simple, budget controller.
SUITABILITY | |||||
---|---|---|---|---|---|
Cable | MOTION Mini | MOTION | EVOLUTION | REVOLUTION | |
Swingtrim | X | X | |||
30-Series | X | X | |||
45-Series | X | X | |||
55 Eco-Series | X | X | |||
55-Series | X | X | X | ||
60-Series | X | X | X | X | |
65-Series | X | X | X | ||
70-Series | X | X | X | ||
85-Series | X | X | X | ||
VERSI-Series | X | X | X |
Downloads
Ditch & Grip Cleaner
OVERVIEW
The perfect tool for removing silt and mud from drainage ditches, this heavy duty attachment is compatible with Power Arms from the 55-series and upwards. It has also be successfully adapted to work with a JCB.
Features and benefits
- 600mm diameter rotary head
- Four cutting blades
- Four throwing blades
- Choice of blades
- Boron steel construction
- Choice of hydraulically operated 0-70 degree or 0-120 degree head rotation
- Ideal for roadside grip clearing
- Adjustable exit spout
- Heavy-duty construction
- Manual or hydraulic chute rotation available
- Weight: 323kg
DITCH AND GRIP CLEANER IN ACTION
See McConnel’s Ditch and Grip cleaner attachment in action:
SUITABILITY | |
---|---|
Ditch Cleaner | |
Swingtrim | |
30-Series | |
45-Series | |
55 Eco-Series | X |
55-Series | X |
60-Series | X |
65-Series | X |
70-Series | X |
85-Series | X |
VERSI-Series | X |
Downloads
Omega Flailhead
OVERVIEW
McConnel’s toughest and most powerful flailhead, the Omega has been created for professional green maintenance specialists tackling dense overgrowth and mature hedgerows.
Built around the Omega rotor, which allows heavy-duty flails to spin through 360 degrees to protect the machine from damage, the flailhead can tackle material up to 100mm in thickness
Features
- Three different working widths from 1.2m to 1.6m
- Heavy-duty rotor and flails
- Direct and belt drive options
- Front flap kit
- Rear flap kit
- Wire trap
- Adjustable front hood
- Robust build quality
- HD front flap kit
- Extremely robust construction
MCCONNEL’S OMEGA ROTOR IN ACTION
See McConnel’s Omega rotor in action:
Models
- 1.2m Omega DD
- 1.2m Omega BD
- 1.5m Omega DD
- 1.5m Omega BD
- 1.6m Omega DD
- 1.6m Omega BD
SUITABILITY | |||
---|---|---|---|
Omega 1.2m | Omega 1.5m | Omega 1.6m | |
Swingtrim | |||
30-Series | |||
45-Series | |||
55 Eco-Series | X | ||
55-Series | X | X | |
60-Series | X | X | |
65-Series | X | X | X |
70-Series | X | X | X |
85-Series | X | X | X |
VERSI-Series | X | X |
Downloads
Multicut Flailhead
OVERVIEW
Ideally suited for professional hedgecutting and verge mowing, this premium range of flailheads is built around the Multicut rotor and features wrap-around lugs which provide excellent strength and protection.
The spiral layout of the lugs ensures that only two flails are cutting at any one time for a smooth, continuous cutting action.
Features
- Four different working widths from 1.2m to 2.0m
- Complete choice of flails
- Direct and belt drive options
- Front flap kit (Heavy duty version available with the 65-series and above)
- Rear flap kit
- Wire trap
- Adjustable front hood
- Optional skid kit
- Inboard and outboard options
- Robust build quality
- Multicut flailheads for 65-series Power Arms and above come with the new F14 T-flail equipped as standard
- Optional cushioned roller *
- Optional hydraulic roller *
- Optional hydraulic hood *
* Not available on the 2.0m model
Models
- 1.2m Multicut DD
- 1.2m Multicut BD
- 1.5m Multicut DD
- 1.5m Multicut BD
- 1.6m Multicut DD
- 1.6m Multicut BD
- 2.0m Multicut DD
- 2.0m Multicut BD
SUITABILITY | ||||
---|---|---|---|---|
Multicut 1.2m | Multicut 1.5m | Multicut 1.6m | Multicut 2.0m | |
Swingtrim | ||||
30-Series | ||||
45-Series | ||||
55 Eco-Series | X | X | ||
55-Series | X | X | ||
60-Series | X | X | ||
65-Series | X | X | X | |
70-Series | X | X | X | |
85-Series | X | X | X | X |
VERSI-Series | X | X |
* Multicut 1.6m and 2.0m flailheads not compatible with telescopic-arm machines
Downloads
Rotary Heads
ROTARY HEAD – FINE CUT
1.2m Fine Cut Rotary Head
Fine Cut Rotary Head
Available with a 1.2m working width and a 25mm cutting capacity
Designed to deliver the best in cut quality, McConnel’s 1.2m FineCut Rotary Head is equipped with two high-speed rotors and eight blades, cutting material up to 25mm thick into a fine mulch.
This not only ensures a fine finish, but also retains most of the debris within the hedge for healthy growth and a tidy finish.
Features and benefits
- 1.2m working widths
- 25mm cutting capacity
- Weight: 130kg
- Left or right hand build options
- Twin rotor, eight blade configuration
- 45 ltr/min oil flow
ROTARY HEADS – MD
1.2m Rotary Head MD, 1.5m Rotary Head MD
Rotary Head MD
A choice of 1.2m and 1.5m working width and a cutting capacity of 100mm
McConnel’s range of MD rotary heads delivers a viable alternative to flail cutting, with a choice of two different working widths, blade or chain cutting options, and rugged build quality.
The MD range delivers a fine cut attractive finish and is compatible with most mid-range and top-end Power Arms.
Features and benefits
- 1.2m and 1.5m working widths
- 100mm cutting capacity
- Chain or blade options
- Hydraulic front hood
- Equally adept at cutting grass and hedges
ROTARY HEADS – HD
1.2m Rotary Head HD, 1.5m Rotary Head HD
Rotary Head HD
A choice of 1.2m and 1.5m working widths and a cutting capacity of 120mm
The toughest and most durable Rotary Heads in the McConnel range are built to last with a choice of two different working widths, blade or chain cutting options and a cutting capacity of up to 100mm.
The HD range delivers an attractive finish and is compatible with top-end Power Arms.
Features and benefits
- 1.2m and 1.5m working widths
- Extremely durable
- 120mm cutting capacity
- Chain or blade options
- Hydraulic front hood
- Equally adept at cutting grass and hedges
ROTARY HEAD IN ACTION
See McConnel’s HD Rotary Head attachment in action:
SUITABILITY | |||
---|---|---|---|
Fine Cut Rotary Head | Rotary Head MD | Rotary Head HD | |
Swingtrim | |||
30-Series | X | ||
45-Series | X | ||
55 Eco-Series | X | X | |
55-Series | X | X | |
60-Series | X | X | |
65-Series | X | X | |
70-Series | X | X | |
85-Series | X | X | |
VERSI-Series |
* Rotary Heads are not compatible with telescopic arm machines.
** 1.5m HD Rotary Head is not compatible with VFR models
Downloads
Multisaws
MULTISAW COMPACT
Compact 1400, Compact 2100, Compact 2800
A choice of 1.4m, 2.1m and 2.8m models is available, each with a cutting capacity of 80mm.
A robust Multisaw with a choice of three different working widths, the Compact range is designed for use with smaller Power Arms and is ideal for farmers, contractors, amenities specialists, and local government.
Quiet enough to use close to residential areas, the machines can tackle material up to 80mm thick, are equally adept at cutting thin and thick vegetation
Features and benefits
- 1.4m, 2.1m, and 2.8m working widths
- Compact 1400: 4-blade configuration
- Compact 2100: 6-blade configuration
- Compact 2800: 8-blade configuration
- 5mm-80mm cutting capacity
- Trapping protection
- Four-blade configuration
- 350mm blade thickness
- Super-strength tungsten carbide Videa teeth
- Minimum oil flow: 40 ltrs/min
MULTISAW SD
Multisaw 1600
The Multisaw SD has a working width of 1.6m and a cutting capacity of 120mm
A robust and powerful four-blade Multisaw with a 1.6m working widths, the SD Multisaw is designed for use with smaller Power Arms and is ideal for farmers, contractors, amenities specialists, and local government.
Quiet enough to use close to residential areas, the machine can tackle material up to 120mm thick and is equally adept at cutting bushes and branches.
Features and benefits
- 1.6m working width
- 5mm-120mm cutting capacity
- Four-blade configuration
- 400mm blade thickness
- Super-strength tungsten carbide Videa teeth
- Minimum oil flow: 50 ltrs/min
MULTISAW HD
Multisaw 2100, 2400
The 2.0m HD Multi saw is available with a 150mm cutting capacity. The 2.4m model has a 200mm cutting capacity
McConnel’s most powerful Multisaws, the HD range offers heavy-duty build quality, working widths up to 2.4m,and a ferocious cutting action capable of tackling material up to 200mm (HD 2400).
Designed for larger Power Arms, the HD range is ideal for farmers, forestry teams, local government, and contractors looking to expand the services they offer.
Features and benefits
- 2.0m, and 2.4m working widths
- 5mm-100mm cutting capacity
- Four-blade configuration
- 500mm blade thickness (HD2000)
- 600mm blade thickness (HD2400)
- Super-strength tungsten carbide Videa teeth
- Minimum oil flow: 50/85 ltrs/min
- Weight: 220kg (HD 2000)
- Weight: 280kg (HD2400)
SUITABILITY | |||
---|---|---|---|
Multisaw Compact | Multisaw SD | Multisaw HD | |
Swingtrim | X | ||
30-Series | X | X | |
45-Series | X | X | |
55 Eco-Series | |||
55-Series | X | ||
60-Series | X | ||
65-Series | X | ||
70-Series | X | ||
85-Series | X | ||
VERSI-Series | X | X | X |
Downloads
Cutterbars
SWINGTRIM CUTTERBARS
Available in 1.2m and 1.5m working widths, the Swingtrim Cutterbar delivers a maximum cutting capacity of 20mm
Created exclusively for the Swingtrim, these specialist cutterbars are light and manoeuvrable.
The cutterbars can be rotated through 270 degrees for the best in cutting flexibility.
Features and benefits
- 20mm cutting capacity
- 1.2m and 1.5m working widths
- Weight: 40kg
- Hard-wearing Carbodux teeth
- Exceptional manoeuvrability
CUTTERBARS SD
MHL150, MHL180, MHL210
Three different working widths are available: 1.5m, 1.8m, and 2.1m with a cutting capacity of 30mm
High-performance cutterbars designed for the regular trimming of hedges and bushes.
McConnel’s SD machines are equipped with special serrated teeth which deliver a fine-cut finish and can tackle material up to 30mm.
Features and benefits
- Choice of 1.5m, 1.8m, and 2.1m working widths
- 30mm cutting capacity
- Minimum oil flow: 16-32 ltrs/min
- 200-400 cuts per minute
- Hard-wearing teeth
- Fingers armed with rounded ends prevent trapping of material
- Easy to replace blades
- Weight: 60-68kg
CUTTERBARS MD
MHS200
A medium-duty cutter bar with a 2.0m working width, the MD Cutterbar has a cutting capacity of 45mm.
A powerful cutterbar designed for maintaining trees, bushes and hedges.
The MD edition is tough and durable and its tungsten-carbide teeth can tackle material up to 45mm thick.
Features and benefits
- 2.0m working width
- 45mm cutting capacity
- 60 cuts per minute
- Minimum oil flow: 45 ltrs/min
- Hardwearing teeth
- Weight: 130kg
- Robust build quality
CUTTERBARS HD
MHX170, MHX230, MHS270
Available in a choice of 1.7m, 2.3m and 2.7m working widths, the HD Cutterbars have a 110mm cutting capacity.
Powerful heavy-duty cutterbars that can tackle material up to 110mm thick.
The HD range is extremely robust and can be used to tackle hedges, bushes, and can even prune trees.
Features and benefits
- 1.7m, 2.3m and 2.7m working widths
- 110mm cutting capacity
- 60 cuts per minute
- Minimum oil flow: 45 ltrs/min
- Hardox steel trimmer bars for exceptional durability
- Hydraulic flow divider
- Soft-turn technology
- Weight: 170-250kg
SUITABILITY | ||||
---|---|---|---|---|
Swingtrim Cutterbar | Cutterbar SD | Cutterbar MD | Cutterbar HD | |
Swingtrim | X | |||
30-Series | X | |||
45-Series | X | X | X | |
55 Eco-Series | X | X | X | |
55-Series | X | X | X | |
60-Series | X | X | X | |
65-Series | X | X | X | |
70-Series | X | X | X | |
85-Series | X | X | X | |
VERSI-Series | X | X | X |
Downloads
Optional Accessories
OVERVIEW
McConnel offers customers a comprehensive range of general accessories – boosting performance, manoeuvrability, safety and functionality, including:
Lift and Angle Float kits
The Lift Float Kit enables the cutting attachment to automatically follow the contours of the ground in a vertical plane, while the Angle Float Kit works in a horizontal plane.
Reducing fatigue by lowering the amount of operator input required, the float kits also increase accuracy, prevent scalping, and boost durability by eliminating excessive wear and tear.
Oil Cooler kit
Improves the performance of Power Arms and prolongs oil life – even in the most arduous conditions.
Safety equipment
McConnel offers road lighting kits, magnetic warning arrows, and window guards, protecting operators and the safety of the public.
Flailhead options
McConnel offers a number of enhancements for flailheads including: Front flap kits, hydraulic rollers, skid kits, and a cushioned grass mowing roller.
Debris Blower
Keeps pavements and roads clear after cutting.
Front Mounting Kit
Enables operators to transform their Power Arm into a front-mount model for enhanced visibility
Orbitor Head
OVERVIEW
Fitting between the cutting attachment and the dipper arm, the Orbitor head bracket gives an extra angle of movement, which enables the Power Arm to cut within the width of the tractor.
Powered by a single ram which is incorporated into the bracket for greater protection, the Orbitor head is an essential tool for those working in confined environments.
Features and benefits
- Ideal for working in narrow lanes
- Enhances manoeuvrability
- Enables cutting within the tractor width
- Operated by in-cab controls
- Light but very durable
- Compact design
ORBITOR HEAD IN ACTION
See McConnel’s orbitor head in action hedge cutting in a narrow lane:
SUITABILITY | |
---|---|
Orbitor | |
Swingtrim | |
30-Series | |
45-Series | X |
55 Eco-Series | X |
55-Series | X |
60-Series | X |
65-Series | X |
70-Series | X |
85-Series | X |
MM-Series | |
VERSI-Series | X* |
* Dependent on model
Downloads
Variable Forward Reach
OVERVIEW
McConnel’s Variable Forward Reach (VFR) armset enables operators to adjust the position of the cutting head alongside the tractor for improved comfort, visibility and safety.
Ideal for both verge-mowing and hedge-cutting, the system is extremely versatile and enables cutting anywhere along an adjustable cutting range from fully forward to behind the tractor.
The technology improves safety by allowing the operator to concentrate on the road ahead; enables operators to set the arm position according to the task or personal preference; and delivers flexible positioning for cutting around obstacles.
Features and benefits
- Improves comfort and visibility
- Reduces fatigue
- Positioning can be tailored to the job or personal preference
- Boosts safety by allowing operators to concentrate on the road ahead
- Enables operators to monitor the cutting attachment
- Ideal for working around street furniture
- Thrives in narrow lanes
VARIABLE FORWARD REACH IN ACTION
See McConnel’s Variable Forward reach armset in action hedge cutting:
SUITABILITY | |
---|---|
Tele-VFR | |
Swingtrim | |
30-Series | |
45-Series | |
55 Eco-Series | |
55-Series | |
60-Series | X |
65-Series | X |
70-Series | X |
85-Series | X |
VERSI-Series |
Downloads
