Hailing from an agricultural background, the Nugent family has designed the Livestock range with the vigour of Ireland’s beef cattle and rugged terrain at the forefront of the design brief. The Nugent Livestock range is engineered and hand built to last and with full type approval (ECWVTA), any farmer will appreciate the attention to detail.
Nugent’s patented Dual Drive™ suspension is standard across the range, enhancing the towing experience and bringing trailer suspension to new levels. The cross member frame braces the front and rear weldment upon a fully welded, galvanised chassis, ensuring maximum strength, while extra reinforcement is given where it’s needed by the folded side panels.
The trailer’s steel sub-frame is fully hot dip galvanised and fitted with a heavy duty steel fabricated dividing gate. These innovative features are combined with years of trailer design expertise to help produce the perfect trailer for the transportation of livestock.
With durable tyres, parabolic leaf spring suspension, solid beam axles and commercial lights, the Nugent Livestock trailer offers superior build quality, strength, longevity and excellent towing characteristics.
The unique design of the sectional fold down front panels facilitates airflow through the trailer whilst in motion, reducing drag and providing for a better towing experience. The added benefit is that less air resistance significantly decreases fuel consumption.
Safety for both animal and farmer is paramount and the Nugent Livestock range is designed to be user friendly . With a variety of sizes, ranging from 8 foot to 14 foot long, Nugent has a Livestock trailer for every requirement.
Nugent Dual Drive™ Suspension
Sectional Fold Down Front Panels
Internal Dividing Gate (except 8 x 5)
Multiple Dividing Gate Hangers
Reinforced Loading Ramp
Robust Taildoor Fastener
Heavy Duty Jockey Wheel
Spare Wheel with support
Aluminium Mudguards (tri axle models)
|Product Code||Imperial Size||Axles||Tyres||Gross Weight||Unladen Weight||Internal LxWxH (mm)||Overall LxWxH (mm)|
|L2415S||8' x 5'||2||165R13C||2,000kg||770kg||2490 x 1530 x 1820||3780 x 2070 x 2310|
|L3015S||10' x 5'||2||165R13C||2,700kg||810kg||3100 x 1530 x 1820||4340 x 2070 x 2310|
|L3018H||10' x 6'||2||195/75R16||3,500kg||1,125kg||3100 x 1805 x 1930||4340 x 2400 x 2470|
|L3618H||12' x 6'||2||195/75R16||3,500kg||1,175kg||3710 x 1805 x 1930||5000 x 2400 x 2470|
|L3618T||12' x 6'||3||195/75R16||3,500kg||1,300kg||3710 x 1805 x 1930||5000 x 2400 x 2470|
|L4318H||14' x 6'||2||195/75R16||3,500kh||1,225kg||4320 x 1805 x 1930||5645 x 2400 x 2470|
|L4318T||14' x 6'||3||195/75R16||3,500kg||1,350kg||4320 x 1805 x 1930||5645 x 2400 x 2470|
